Product Description
Allen-Bradley 2080-L50E-24QBB
The Allen-Bradley 2080-L50E-24QBB is a high-performance Micro850 Programmable Logic Controller (PLC) designed for larger standalone machine control applications that require flexible communication and advanced I/O capabilities. Part of the Micro800 family, this controller features 24 embedded digital I/O points and an integrated 10/100 Base-T Ethernet/IP port for seamless network integration. It supports up to four expansion I/O modules, providing scalability for growing application needs. The 2080-L50E-24QBB is programmed using the free Connected Components Workbench (CCW) software, offering a user-friendly environment for configuration, programming, and visualization. Its support for Pulse Train Outputs (PTO) makes it suitable for simple motion control tasks.
Technical Specifications:
- Controller Type: Micro850
- Input Power: 24V DC
- Embedded I/O: 14 Digital Inputs (24V DC/AC), 10 Digital Sourcing Outputs (24V DC)
- Communication Ports: Embedded 10/100 Mbps Ethernet/IP, Embedded non-isolated RS232/485 serial port
- Expansion I/O: Supports up to 4 Micro800 expansion I/O modules
- Motion Control: Supports up to 3 axes of motion via Pulse Train Output (PTO)
- Programming Software: Connected Components Workbench (CCW)
Allen-Bradley 2080-L50E-24QBB
Discover the Allen-Bradley 2080-L50E-24QBB, a Micro850 24-point PLC controller featuring an embedded Ethernet/IP port. This compact and expandable controller is ideal for cost-effective automation and standalone machine control applications.
