Product Description
National Instruments UMI-7764
The National Instruments UMI-7764 is a Universal Motion Interface designed to simplify the process of connecting motors, encoders, and I/O signals to NI 73xx series motion controllers. This versatile breakout box provides a robust and organized wiring solution, featuring standard D-SUB connectors for motor drives and encoder feedback. Its DIN-rail mountable design makes it easy to integrate into control cabinets and systems. The UMI-7764 effectively bridges the high-density 68-pin VHDCI connector on the motion controller to easily accessible screw terminals or D-SUB connectors, significantly reducing setup time and potential wiring errors in prototyping and deployment of motion control applications.
Technical Specifications:
- Compatibility: Designed for use with National Instruments 733x, 734x, and 735x series motion controllers.
- Controller Connection: One 68-pin VHDCI male connector for linking to the motion controller.
- Motor/Encoder Connectivity: Features four 25-pin D-SUB connectors for motor drive connections and four 9-pin D-SUB connectors for encoder feedback.
- Mounting: DIN-rail mountable for easy and secure installation in industrial enclosures.
National Instruments UMI-7764
The National Instruments UMI-7764 is a Universal Motion Interface that simplifies wiring for NI 73xx motion controllers, providing a reliable breakout solution for connecting stepper/servo motors, encoders, and I/O signals via D-SUB connectors.
