Product Description
PLEIGER IO 8/8/4 CAN Module
The PLEIGER IO 8/8/4 is a versatile Input/Output module designed for integration into the Pleiger PLS automation and control systems, commonly used in marine and industrial applications. It serves as an interface between the central control unit and field devices like sensors and actuators. This specific module configuration provides a balance of digital and analog I/O channels, communicating reliably over a CAN bus network (typically CANopen protocol) for decentralized signal processing and control tasks.
Technical Specifications:
- Module Type: Input/Output Module
- Digital Inputs: 8 (Typically 24V DC)
- Digital Outputs: 8 (Typically 24V DC, potential-free contacts or transistor)
- Analog Inputs/Outputs: 4 (Configurable, e.g., 0-10V, 4-20mA)
- Communication Interface: CAN bus (CANopen protocol)
- Supply Voltage: 24V DC
- Connection Type: Pluggable screw terminals or specific connectors (depending on variant)
- Mounting: DIN Rail (Typical)
- Operating Temperature: Check specific variant datasheet (Often -20°C to +70°C)
- Protection Class: Check specific variant datasheet (Often IP20)
