Product Description
Allen-Bradley 1734-OE2VK Analog output module
The Allen-Bradley 1734-OE2VK is a high-performance analog output module from the POINT I/O family. It is designed to provide two individually isolated analog output channels, offering exceptional flexibility for various industrial control applications. This module can be configured to output either voltage (0-10V, ±10V) or current (0-20mA, 4-20mA) signals, allowing it to interface with a wide range of devices such as drives, valves, and indicators. Its compact, modular design saves valuable panel space and simplifies system expansion. The 1734-OE2VK delivers high-resolution, 16-bit performance, ensuring precise and reliable control in demanding automation environments.
Technical Specifications:
- Module Type: 2 Channel Isolated Analog Voltage/Current Output
- Output Range (Voltage): 0…10V, ±10V
- Output Range (Current): 0…20 mA, 4…20 mA
- Resolution: 16 bits (15 bits + sign) across user-selectable range
- POINTBus Current: 75 mA @ 5V DC
- Power Dissipation: 1.0 W max @ 28.8V DC

Allen-Bradley 1734-OE2VK Analog output module
Discover the Allen-Bradley 1734-OE2VK, a 2-channel isolated analog voltage/current output module for the POINT I/O system. Ideal for precise control of industrial actuators and devices.
