Product Description
Allen-Bradley 1769-IF8 8 Channel Analog Input Module
The Allen-Bradley 1769-IF8 is a highly versatile Compact I/O 8-Channel Analog Input Module designed to interface seamlessly with your industrial control systems. This robust module supports a wide variety of input ranges, including both current (0-20mA, 4-20mA) and voltage (+/-10VDC, 0-5VDC, 0-10VDC, 1-5VDC) signals, providing exceptional flexibility for diverse automation applications. Built for reliability in demanding environments, it features a Class I Division 2 hazardous location rating and operates efficiently with low bus current draw. The 1769-IF8 is an essential component for precise data acquisition and process monitoring in Allen-Bradley CompactLogix and MicroLogix 1500 systems.
Technical Specifications:
- Brand: Allen-Bradley
- Model/Catalog Number: 1769-IF8
- Product Type: Compact I/O Analog Input Module
- Number of Channels: 8
- Input Ranges (Current): 0-20mA, 4-20mA
- Input Ranges (Voltage): +/-10VDC, 0-5VDC, 0-10VDC, 1-5VDC
- Bus Current Draw @ 5VDC: 0.12A
- Bus Current Draw @ 24VDC: 0.07A
- Firmware Revision: 1.1
- Power Supply Distance Rating: 8 modules
- Hazardous Location Rating: Class I, Division 2, Groups A, B, C, D (Temp Code T3C)
- Certifications: UL Listed, CE, KC, Class 2 Rated
Allen-Bradley 1769-IF8 8 Channel Analog Input Module
Optimize your industrial automation with the Allen-Bradley 1769-IF8 Compact I/O 8-Channel Analog Input Module. Featuring versatile voltage and current input ranges, low power consumption, and Class I Div 2 certification, this reliable module delivers precise data acquisition for your CompactLogix PLC systems.
| Brand | Allen-Bradley |
|---|---|
| Model | 1769-IF8 |
| Part No. | 1013940435074 |
| Category | Electrical |
