Product Description
Allen-Bradley 22B-D2P3N104
The Allen-Bradley 22B-D2P3N104 is a PowerFlex 40 AC Drive, engineered to deliver versatile and reliable speed control for three-phase induction motors. Part of the renowned PowerFlex family, this drive features Sensorless Vector Control, which provides excellent torque and speed regulation, making it ideal for a wide range of applications including fans, pumps, conveyors, and material handling systems. This specific model operates on a 480V AC input and is rated for 1.0 HP. It includes an integral EMC filter to help meet CE requirements and mitigate electromagnetic interference. The compact, open-type enclosure allows for easy panel mounting and integration into existing control cabinets.
Technical Specifications:
- Voltage Rating: 480V AC
- Power Rating: 0.75 kW / 1.0 HP
- Output Current: 2.3 Amps
- Input Phase: 3-Phase
- Enclosure: IP20, NEMA/UL Type Open
- Frame Size: A
- Filtering: With EMC Filter
- Operator Interface: Blank Cover (No HIM)
Allen-Bradley 22B-D2P3N104
Purchase the Allen-Bradley 22B-D2P3N104 PowerFlex 40 AC Drive. This 1.0 HP, 480V, 3-phase VFD provides reliable motor speed control with an integrated EMC filter in a compact, panel-mount design.
| Brand | Allen-Bradley |
|---|---|
| Model | 22B-D2P3N104 |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/allen-bradley-22b-d2p3n104 |
