Product Description

ARMATUREN ARI-PREMIO

The ARMATUREN ARI-PREMIO is a versatile and robust electric linear actuator designed for the precise and reliable operation of control valves in various industrial applications. It offers a range of actuating forces and stroke lengths, ensuring compatibility with different valve sizes and process requirements. Known for its durability and ease of integration, the ARI-PREMIO series can be equipped with various control options and accessories to meet specific automation needs, contributing to efficient process control and plant safety.

Technical Specifications:

Type: Electric Linear Actuator
Actuating Force: Available from 2.2 kN to 25 kN (depending on specific model)
Stroke: Up to 100 mm (depending on specific model and configuration)
Supply Voltage: Options typically include 230V AC, 115V AC, 24V AC/DC (model dependent)
Protection Class: IP65 (standard)
Ambient Temperature: Typically -20°C to +70°C (may vary by model)
Control Signal: Standard 3-point step control; optional continuous control (e.g., 0/4-20mA, 0-10V) with integrated or external positioner
Manual Override: Handwheel for emergency operation (standard on most models)
Mounting: Designed for direct mounting on ARI control valves
