Product Description
AutomationDirect EA9-T8CL Touch panel
The AutomationDirect EA9-T8CL is a high-performance 8-inch color TFT touch screen HMI from the C-more series, designed for demanding industrial automation applications. It features a bright, 800 x 600 SVGA resolution display with 65,536 colors, providing clear and vibrant graphics for machine control and process monitoring. With extensive connectivity options including an Ethernet port, two USB-A ports, one USB-B port, and a multi-protocol serial port (RS-232/422/485), the EA9-T8CL integrates seamlessly with a wide range of PLCs and other industrial devices. Its robust NEMA 4/4X and IP65-rated bezel ensures reliable operation in harsh environments. Programming is simplified with the free, intuitive C-more EA9 series software, making this touch panel a cost-effective and powerful solution for any HMI project.
Technical Specifications:
- Display Size: 8-inch diagonal TFT LCD
- Resolution: 800 x 600 pixels (SVGA)
- Display Colors: 65,536 (16-bit)
- Touchscreen Type: Analog Resistive
- Backlight: LED
- Project Memory: 82 MB
- Communication Ports: 1 x Ethernet 10/100 Base-T (RJ45), 1 x Serial (RS-232/422/485), 2 x USB Type A, 1 x USB Type B
- Power Requirement: 12-24 VDC
- Enclosure Rating: NEMA 4/4X, IP65 (indoor use only) when properly installed
AutomationDirect EA9-T8CL Touch panel
The AutomationDirect EA9-T8CL is a reliable 8-inch C-more HMI touch panel featuring an 800×600 SVGA color display, Ethernet and serial connectivity, and a NEMA 4/4X rating for industrial environments.
| Brand | Automationdirect |
|---|---|
| Model | EA9-T8CL Touch panel |
| Category | Electrical |
