Product Description
Azbil SDC36 Digital Indicating Controller
The Azbil SDC36 is a high-performance digital indicating controller featuring a large, easy-to-read 5-digit, 2-line display. It offers a fast sampling cycle of 25 ms and achieves a high accuracy of ±0.1% FS, making it ideal for precise temperature and process control applications. The SDC36 is equipped with Azbil’s advanced “Ra-PID” (RationaLOOP PID) and “Just-FiTTER” autotuning algorithms, ensuring optimal control stability and responsiveness. Its versatile design supports universal inputs (thermocouple, RTD, voltage/current) and multiple control output types, providing flexibility for a wide range of industrial processes in sectors like manufacturing, heat treatment, and packaging.
Technical Specifications:
- Model: SDC36 (C36TR0UA1000)
- Control Type: ON/OFF, PID Control with “Ra-PID” and “Just-FiTTER” autotuning
- Input Type: Universal (Thermocouple, RTD, DC Voltage/Current)
- Control Output: Relay contact, Voltage pulse (for SSR), Current (4-20 mA DC) – depending on model
- Accuracy: ±0.1% of full scale ±1 digit
- Sampling Cycle: 25 ms
- Display: 5-digit, 2-line LCD display (PV/SV)
- Power Supply: 100 to 240 V AC, 50/60 Hz
- Dimensions: 96 x 96 mm (DIN standard)
Azbil SDC36
Discover the Azbil SDC36, a high-accuracy digital indicating PID controller with a fast 25ms sampling rate. Ideal for precise temperature and process control, it features a large 5-digit display and advanced autotuning.
