Product Description
Balluff BES02K0
The Balluff BES02K0 (BES M18MI-PSC80B-S04G) is a high-quality inductive sensor designed for reliable non-contact detection of metallic objects in industrial automation applications. Housed in a robust M18 nickel-plated brass body, this sensor is built to withstand harsh environments, boasting an IP68 protection rating. Its standard M12 connector ensures quick and secure installation, while the flush mountable design allows for seamless integration into machinery. Ideal for position sensing, counting, and control tasks, the BES02K0 provides consistent and accurate performance.
Technical Specifications:
- Model: BES M18MI-PSC80B-S04G
- Sensing Range: 8 mm
- Housing Size: M18x1
- Mounting Type: Flush mountable
- Output Function: PNP Normally Open (NO)
- Operating Voltage: 10…30 V DC
- Connection: M12x1 Connector, 4-pin
- IP Protection Rating: IP68

Balluff BES02K0
Discover the Balluff BES02K0, a robust M18 flush-mountable inductive sensor with an 8mm sensing range. This PNP NO sensor provides reliable metal detection for industrial automation systems.
