Beckhoff CX8093
The Beckhoff CX8093 is a compact, DIN rail-mountable Embedded PC designed for building automation applications. It functions as a BACnet/IP controller, capable of serving as a protocol converter or a decentralized controller. Equipped with an ARM Cortex™-A8 processor, it provides robust performance for a wide range of control tasks. The device features two switched Ethernet ports and an integrated E-bus/K-bus interface for direct connection to Beckhoff Bus Terminals. Programmed with TwinCAT 2, the CX8093 is a versatile and efficient solution for intelligent building control systems, HVAC, and room automation.
Technical Specifications:
- Processor: ARM Cortex™-A8, 600 MHz
- Operating System: Microsoft Windows Embedded Compact 7
- Main Memory: 256 MB DDR3 RAM
- Flash Memory: 512 MB microSD (pluggable)
- Interfaces: 2 x RJ45 (10/100 Mbit/s, switched), 1 x USB 2.0
- Protocol: BACnet/IP
- Programming: TwinCAT 2 PLC runtime
- Bus Interface: E-bus or K-bus, automatic recognition
Beckhoff CX8093
Discover the Beckhoff CX8093 Embedded PC, a compact and powerful BACnet/IP controller ideal for building automation, HVAC, and decentralized control systems. Features a 600 MHz ARM processor and TwinCAT 2 runtime.
| Brand | BECKHOFF |
|---|---|
| Model | CX8093 |
