Product Description
Beckhoff KL3051
The Beckhoff KL3051 is a single-channel analog input terminal designed for the Beckhoff Bus Terminal system. It efficiently processes signals within the -10 to +10 V range. The input voltage is digitized with a high resolution of 12 bits and is transmitted, electrically isolated, to the higher-level automation device. The input channel of the KL3051 is a differential input. This terminal is ideal for precise data acquisition in various industrial control and measurement applications, offering reliable performance with a fast conversion time and minimal measurement error.
Technical Specifications:
- Technology: Analog input
- Number of inputs: 1
- Signal voltage: -10…+10 V
- Resolution: 12 bit
- Conversion time: approx. 100 µs
- Measurement error: < ±0.1 % (relative to full scale value)
- Current consumption K-bus: typ. 30 mA
Beckhoff KL3051
Purchase the Beckhoff KL3051, a high-performance single-channel analog input terminal for -10V to +10V signals. Features 12-bit resolution and fast conversion, ideal for precise industrial automation and control systems.
