Product Description

Burkert 00142953 – Solenoid Coil Type 2508

The Burkert 00142953 is a high-performance solenoid coil, Type 2508, designed for reliable operation of Burkert solenoid valves. This coil is engineered for continuous duty (100% ED) and features a durable polyamide encapsulation that provides excellent protection against mechanical stress, humidity, and aggressive media. Its compact, energy-efficient design and simple click-on mounting system allow for quick, tool-free installation and replacement, making it a preferred choice for a wide range of industrial applications, including process control, automation, and fluid technology.

Technical Specifications:

  • Part Number: 00142953
  • Type: 2508
  • Voltage: 24V DC
  • Power Consumption: 8 W
  • Duty Cycle: 100% ED (Continuous Duty)
  • IP Rating: IP65 (with cable plug attached)
  • Electrical Connection: DIN EN 175301-803 Form A
  • Ambient Temperature Range: -40 °C to +55 °C
  • Coil Encapsulation Material: Polyamide (PA)
  • Voltage Tolerance: ±10%

Burkert 00142953

Model:Burkert 00142953
