Product Description
Buschjost 8452400.0000
The Buschjost 8452400.0000 is a high-performance 2/2-way pilot-operated solenoid diaphragm valve designed for robust and reliable fluid control. Featuring a durable brass body and NBR sealing, this valve is engineered for controlling neutral gaseous and liquid fluids across a wide pressure range. As a normally closed (NC) valve, it ensures a secure shut-off when de-energized. This model is part of the proven IMI Buschjost series, known for its quality and longevity in various industrial applications. Please note that the solenoid coil/actuator is not included and must be ordered separately to match your specific voltage requirements.
Technical Specifications:
- Function: 2/2-way, Normally Closed (NC)
- Actuation: Pilot-operated
- Port Size: G 1/2
- Operating Pressure: 0.3 to 16 bar (4.35 to 232 psi)
- Orifice Size: 13 mm
- Body Material: Brass
- Seal Material: NBR (Nitrile Butadiene Rubber)
- Media Temperature: -10°C to +90°C (+14°F to +194°F)
- Kv Value: 4.5 m³/h

Buschjost 8452400.0000
Discover the Buschjost 8452400.0000, a reliable G 1/2 2/2-way normally closed solenoid valve. Built with a brass body and NBR seal, it’s ideal for controlling neutral fluids from 0.3 to 16 bar.
