Product Description

Consilium CS-LOOP M

The Consilium CS-LOOP M is a high-performance Loop Driver Module designed specifically for the Salwico CS4000 addressable fire detection system. This essential component serves as the interface between the central control unit and the addressable loop units, such as smoke detectors, heat detectors, and manual call points. It provides both power and communication to the loop, continuously monitoring the status of all connected devices for alarms or fault conditions. Engineered for reliability in demanding marine and industrial environments, the CS-LOOP M ensures the integrity and swift response of your fire safety system.

Technical Specifications:

  • Part Number: 5200021-00A

  • System Compatibility: Salwico CS4000 Fire Detection System

  • Function: Addressable Loop Driver Module

  • Loop Capacity: Up to 254 addressable units

  • Power Supply: Via CS4000 backplane

  • Current Consumption: 35 mA @ 24 VDC (from backplane)

Consilium CS-LOOP M Description

Consilium CS-LOOP M

Buy the Consilium CS-LOOP M Loop Driver Module, a vital component for the Salwico CS4000 addressable fire detection system. Ensures reliable communication and power for your marine and industrial safety loops.
