Product Description
Consilium ST450EC
The Consilium ST450EC is a sophisticated and reliable combined marine instrument, integrating a one-axis Doppler Speed Log and an Echo Sounder into a single, compact system. Designed for a wide range of vessels, it provides crucial, real-time data on speed through water (STW) and depth, essential for safe navigation, docking, and efficient passage planning. Featuring a clear 7-inch color TFT display, the ST450EC presents information intuitively. It is fully compliant with the latest IMO resolutions and holds MED (Wheelmark) approval, making it a suitable replacement for older systems and an excellent choice for new builds requiring high-performance navigational equipment.
Technical Specifications:
- System Type: Combined one-axis water track speed log and echo sounder
- Speed Range: +/- 40 knots ahead/astern
- Depth Range: 0.5 – 400 meters
- Operating Frequencies: 2 MHz (Speed Log) / 200 kHz (Echo Sounder)
- Display: 7-inch Color TFT, 800×480 pixels
- Power Supply: 115/230 VAC, 50-60 Hz or 24 VDC
- Compliance: IMO Resolutions A.824(19), MSC.96(72), MSC.334(90), IEC 61023, IEC 62288, IEC 60945, IEC 61162-1/2
Consilium ST450EC
The Consilium ST450EC is an IMO-compliant combined Doppler Speed Log and Echo Sounder, providing accurate speed and depth data for safe and efficient marine navigation.
