Product Description
DURAG D-LX701UA-30
The DURAG D-LX701UA-30 is a compact and self-monitoring flame monitor designed for the reliable detection of flames in continuous operation. It is suitable for a wide range of industrial applications, including power stations, chemical plants, and incinerators. This model utilizes UV radiation technology to detect flames from various fuels such as gas, oil, and coal. Its robust design ensures fail-safe performance even in harsh environments, featuring a high protection rating and a wide operating temperature range. The D-LX701UA-30 provides both a relay output for the flame signal and a 4-20mA analog output for monitoring flame intensity, making it a versatile solution for modern combustion control systems.
Technical Specifications:
- Spectral Range: UV, 190 to 270 nm
- Supply Voltage: 24 VDC
- Ambient Temperature: -40°C to +85°C
- Protection Rating: IP67
- Outputs: Relay contact (flame signal), 4-20mA (flame intensity)
- Safety Integrity Level: SIL3 certified
DURAG D-LX701UA-30
DURAG D-LX701UA-30 compact UV flame monitor for continuous industrial combustion monitoring. Features 24 VDC supply, IP67 protection, 4-20mA output, and SIL3 certification for fail-safe operation.
