Product Description
Dwyer 616KD-14-V-TC
The Dwyer 616KD-14-V-TC is a compact and reliable differential pressure transmitter designed for monitoring pressure and flow in various HVAC and industrial applications. It features the patented One-Touch® technology, which simplifies zero and span calibration by eliminating the need for trim pots and allowing adjustments with a single push-button. This model is ideal for measuring the pressure of air and non-combustible, compatible gases with high accuracy. Its robust design and user-friendly interface make it a top choice for monitoring filter status, duct static pressure, and room pressurization.
Technical Specifications:
- Service: Air and non-combustible, compatible gases.
- Range: 0 to 10″ w.c. (0 to 2.5 kPa).
- Accuracy: ±1.0% FS.
- Output Signal: 4 to 20 mA (2-wire).
- Power Requirements: 10 to 35 VDC.
- Temperature Limits: 0 to 140°F (-18 to 60°C).
- Process Connections: Barbed, for 3/16″ I.D. tubing.
- Enclosure Rating: NEMA 1 (IP20).
- Special Feature: Includes NIST traceable calibration certificate (TC).
Dwyer 616KD-14-V-TC
Shop the Dwyer 616KD-14-V-TC One-Touch® Differential Pressure Transmitter. This unit provides a 0-10″ w.c. range, 4-20 mA output, and includes a NIST certificate for reliable air pressure monitoring.
