Product Description
Dwyer ADPS-05-WP
The Dwyer ADPS-05-WP is an adjustable differential pressure switch designed for monitoring low pressures, vacuums, and differential pressures of air or other non-combustible, non-aggressive gases. This model features a robust NEMA 4X (IP66) weatherproof enclosure, making it ideal for outdoor installations or harsh industrial environments where protection against dust, dirt, and water ingress is critical. The set point can be easily adjusted in the field using an internal screw, offering convenience and precision for various applications such as HVAC, filter status monitoring, fan control, and duct pressure supervision. Its compact design and reliable performance make it a popular choice for ensuring optimal system operation.
Technical Specifications:
- Service: Air and non-combustible, compatible gases
- Wetted Materials: Diaphragm: Silicone; Housing: Polycarbonate
- Adjustable Range: 0.16″ to 1.2″ w.c. (40 to 300 Pa)
- Maximum Pressure: 40 in w.c. (10 kPa)
- Temperature Limits: -4 to 185°F (-20 to 85°C)
- Switch Type: SPDT (Single Pole Double Throw)
- Electrical Rating: 1.5 A @ 250 VAC~; 1 A @ 30 VDC (resistive load)
- Electrical Connections: Screw terminal block
- Conduit Connection: 1/2″ NPT female or M20 x 1.5 with cable gland (included)
- Process Connections: Barbed for 3/16″ (5 mm) ID tubing
- Enclosure Rating: NEMA 4X (IP66)
- Mounting Orientation: Diaphragm in vertical position
- Set Point Adjustment: Internal screw
- Deadband: Approximately 0.08″ w.c. (20 Pa)
- Weight: Approximately 0.49 lb (220 g)
- Approvals: CE, RoHS
Dwyer ADPS-05-WP
Model:Dwyer ADPS-05-WP
