Product Description
Eaton PVH131R02AF30B250000002001AB010A Hydraulic Piston Pump
The Eaton Vickers PVH131R02AF30B250000002001AB010A is a heavy-duty, variable displacement axial piston pump engineered for demanding high-pressure industrial hydraulic applications. Part of the highly regarded PVH series, this pump features a robust cast iron housing finished with a durable blue industrial coating to withstand harsh operating environments. It comes equipped with a splined input shaft for reliable, high-torque drive coupling and an integrated hydraulic control valve assembly for precise system management. Designed with an SAE standard mounting flange, it ensures seamless integration and exceptional fluid power efficiency for modern industrial machinery.
Technical Specifications:
- Brand: Eaton / Vickers
- Model Number: PVH131R02AF30B250000002001AB010A
- Assembly Number (ASSY): 02-334086
- Pump Type: Variable Displacement Axial Piston Pump
- Displacement: 131 cc/rev (8.0 in³/rev)
- Rotation: Right-Hand (Clockwise)
- Mounting: SAE Standard Flange
- Country of Origin: Made in U.S.A.
Eaton PVH131R02AF30B250000002001AB010A Hydraulic Piston Pump
Upgrade your industrial hydraulic systems with the Eaton Vickers PVH131R02AF30B250000002001AB010A variable displacement axial piston pump (Assy: 02-334086). Delivering 131cc/rev displacement, this heavy-duty, USA-made pump features a rugged cast iron housing, splined shaft, and SAE mounting for reliable, high-pressure performance.
