Product Description
ELCO OSM90B-KL10000V2BLI6Q12.1
The ELCO OSM90B-KL10000V2BLI6Q12.1 is a high-performance incremental rotary encoder designed for demanding industrial applications. Featuring a robust 90mm housing and a solid 6mm shaft, it provides reliable and precise measurement of angle, position, and rotational speed. Its high resolution of 10,000 pulses per revolution ensures exceptional accuracy for tasks in automation, robotics, and machine control. The push-pull (HTL) output circuit and wide supply voltage range make it a versatile and compatible solution for integration into various control systems.
Technical Specifications:
- Model: OSM90B-KL10000V2BLI6Q12.1
- Type: Incremental Optical Rotary Encoder
- Resolution: 10,000 Pulses Per Revolution (PPR)
- Output Circuit: Push-pull (HTL)
- Supply Voltage: 10-30 VDC
- Shaft Type: 6 mm solid shaft
- Housing Diameter: 90 mm
- Connection: 1m cable with 12-pin M23 connector, radial outlet
ELCO OSM90B-KL10000V2BLI6Q12.1
Discover the ELCO OSM90B-KL10000V2BLI6Q12.1, a robust incremental rotary encoder with 10,000 PPR resolution, 6mm solid shaft, and a 10-30 VDC push-pull (HTL) output. Ideal for precise position and speed control in industrial automation.
| Brand | ELCO |
|---|---|
| Model | OSM90B-KL10000V2BLI6Q12.1 |
| Category | Electrical |
