Product Description

Endress +Hauser FTW325-A2A1A

The Endress+Hauser FTW325-A2A1A is a robust and reliable point level switch from the Liquiphant T series, designed for universal application in all types of liquids. Operating on the tuning fork principle, it provides dependable level detection for overfill prevention or pump dry-run protection in tanks, vessels, and pipelines. This specific model is ideal for use in non-hazardous areas and features a compact design for easy installation in space-constrained applications. Its plug-and-play functionality requires no calibration or adjustment, ensuring a maintenance-free and cost-effective solution for industrial process control.

Technical Specifications:

  • Principle: Vibrating tuning fork for liquid level detection

  • Output: Two-wire 19…253V AC

  • Process Connection: Thread ISO228 G 1/2 A, 316L Stainless Steel

  • Process Temperature Range: -40 °C to +150 °C (-40 °F to +302 °F)

  • Housing: Plastic housing with IP65/IP67 NEMA4X protection

Endress +Hauser FTW325-A2A1A Description

Endress +Hauser FTW325-A2A1A

Shop the Endress+Hauser FTW325-A2A1A Liquiphant T, a compact tuning fork point level switch for reliable liquid level detection. Ideal for overfill prevention and pump protection in non-hazardous areas.
