Product Description
Euchner EKS-A-IEXA-G01-ST02/03/04
The Euchner EKS-A-IEXA-G01 series is a robust Electronic-Key-System (EKS) adapter designed for reliable access control and management in potentially explosive atmospheres. Certified for ATEX and IECEx environments, this device ensures safe operation in hazardous areas. It features an integrated evaluation module that reads data from an Electronic-Key and transmits it to the control system via two short-circuit-proof transistor outputs. This integration simplifies installation and commissioning. The EKS system allows for the controlled assignment of access rights for operation, setup, and maintenance tasks, significantly enhancing operational safety and process security on industrial machinery and plants.
Technical Specifications:
- Approvals: BVS 11 ATEX E 122 X, IECEx BVS 11.0104X
- Ex marking: II 2G Ex ib IIC T4 Gb, II 2D Ex ib IIIC T135°C Db
- Operating Voltage: 24 V DC -15% / +10% (PELV)
- Outputs: 2 transistor outputs, p-switching, short-circuit-proof
- Degree of Protection: IP67
- Ambient Temperature: -20 °C to +60 °C
- Housing Material: Die-cast zinc, nickel-plated
Euchner EKS-A-IEXA-G01-ST02/03/04
Discover the Euchner EKS-A-IEXA-G01-ST02/03/04, a robust Electronic-Key-System adapter for secure access control in ATEX/IECEx hazardous areas. Features integrated evaluation and a durable IP67 housing for enhanced industrial safety.
