Product Description
GMH 3530 Digital Manometer
The Greisinger GMH 3530 is a high-precision, handheld digital manometer designed for accurate pressure measurement of non-corrosive and non-ionising gases. Equipped with an integrated relative pressure sensor, this robust instrument is ideal for a wide range of applications in industrial settings, HVAC, laboratory environments, and field service. It features a built-in data logger for recording measurements over time, a clear 4½-digit LCD display, and the ability to switch between multiple pressure units (mbar, bar, Pa, kPa, MPa, mmHg, PSI, mH₂O). The GMH 3530 also includes an analog output and serial interface, making it a versatile tool for process monitoring and quality control.
Technical Specifications:
- Measuring Range: -1999 to +2500 mbar (relative)
- Accuracy: < 0.2 % FS (Hysteresis and Linearity)
- Pressure Connections: Two universal pressure ports for 6×1 mm or 8×1 mm tubing
- Features: Integrated data logger, analog output (0-1V), Min/Max value memory, Tare function
- Power Supply: 9V battery or external 10.5-12V DC adapter
GMH 3530
Discover the Greisinger GMH 3530, a high-precision handheld digital manometer with a data logger, ideal for accurate relative pressure measurement in industrial and laboratory applications.
| Brand | GMH |
|---|---|
| Model | 3530 |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/gmh-3530 |
