Product Description
Jumo 704025/0-22
The Jumo 704025/0-22 is a model from the LOGOSCREEN 601 series of paperless recorders. This versatile device is designed for the electronic acquisition, visualization, and archiving of process data. It features a brilliant 5.7-inch TFT color screen for clear and intuitive display of measurement values in various formats, such as vertical/horizontal diagrams, bar graphs, or numerical displays. With its compact design, secure data storage on internal memory or USB flash drives, and a range of communication interfaces including Ethernet and RS485, the LOGOSCREEN 601 is ideal for a wide array of industrial applications, including process monitoring, quality assurance, and plant maintenance. The integrated web server allows for convenient remote monitoring and configuration via a standard web browser.
Technical Specifications:
- Model: LOGOSCREEN 601
- Display: 5.7″ (14.5 cm) TFT color graphics display, 320 x 240 pixels
- Inputs: Configurable with up to 6 universal analog inputs and 6 digital inputs
- Internal Memory: 1 GB for data recording
- Interfaces: Ethernet (Modbus/TCP, web server), USB host (for USB flash drive), RS485 (Modbus RTU master/slave)
- Power Supply: AC 110 to 240 V, +10% / -15%, 48 to 63 Hz or DC 20 to 30 V
- Protection Rating: IP65 (front), IP20 (rear)
Jumo 704025/0-22
The Jumo 704025/0-22 LOGOSCREEN 601 is a compact paperless recorder with a 5.7″ color display, offering reliable process data acquisition, visualization, and storage with Ethernet and USB connectivity.
| Brand | JUMO |
|---|---|
| Model | 704025/0-22 |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/jumo-704025-0-22 |
