Product Description
LG/LS SV015iC5-1
The LG/LS SV015iC5-1 is a compact and cost-effective micro variable frequency drive (VFD) from the iC5 series. Designed for controlling the speed of 3-phase AC motors up to 1.5 kW (2 HP), it operates on a single-phase 200-230V power supply. This inverter is renowned for its user-friendly interface, compact design, and robust performance. It features both V/f and sensorless vector control methods, providing precise and efficient motor operation. With built-in features like PID control, Modbus RTU communication via RS-485, and various protective functions, the SV015iC5-1 is an ideal solution for a wide range of small-scale applications such as fans, pumps, conveyors, and other general-purpose machinery.
Technical Specifications:
- Model: SV015iC5-1
- Power Rating: 1.5 kW / 2 HP
- Input Voltage: 1-Phase 200-230V AC (+10%, -15%), 50/60Hz
- Output: 3-Phase 0-Input Voltage, 0.1-400Hz
- Rated Output Current: 8.0A
- Control Method: V/f control, Sensorless vector control
- Communication: Built-in RS-485 (LS Bus / Modbus RTU)
- Enclosure Rating: IP20
LG/LS SV015iC5-1
Discover the LS Electric SV015iC5-1, a compact 1.5kW (2HP) variable frequency drive. This single-phase 230V inverter offers powerful V/f and sensorless vector control, perfect for optimizing motor speed in pumps, fans, and conveyors.
