Product Description
M-SYSTEM M2DYS-24A-R2/N Current Loop Supply / Signal Isolator
The M-SYSTEM M2DYS-24A-R2/N is a high-performance, compact plug-in signal conditioner designed to power a 2-wire transmitter and isolate its process signal. It reliably converts a 4-20mA DC input into two independent, isolated 4-20mA DC outputs. This unit is essential for eliminating ground loop problems, reducing signal noise, and protecting sensitive control system I/O from field-side transients. Its plug-in design allows for easy installation and maintenance on a DIN rail, making it an ideal choice for high-density applications in industrial automation and process control environments.
Technical Specifications:
- Model: M2DYS-24A-R2/N
- Function: 2-Wire Transmitter Isolator (Current Loop Supply)
- Input Signal: 4 – 20mA DC
- Transmitter Supply: 24 – 27V DC
- Output Signal: 2 isolated outputs, 4 – 20mA DC each
- Power Supply: 24V DC ±10%
- Isolation: Input to Output 1 to Output 2 to Power
- Mounting: DIN Rail
M-SYSTEM M2DYS-24A-R2/N Current Loop Supply / Signal Isolator
Discover the M-SYSTEM M2DYS-24A-R2/N, a reliable dual-output signal isolator and current loop supply. It provides isolated 24V DC power to a field transmitter and converts a 4-20mA input into two fully isolated 4-20mA outputs, perfect for eliminating ground loops and protecting industrial control systems.
| Brand | M-SYSTEM |
|---|---|
| Model | M2DYS-24A-R2/N |
| Part No. | 965097440934 |
| Category | Electrical |
