Product Description
Marsen V-CON
The Marsen V-CON is an advanced differential pressure flow meter designed for high-accuracy and reliable measurement of liquid, gas, and steam flows in a wide range of industrial applications. Its innovative V-shaped cone element conditions the fluid flow, creating a stable and well-defined pressure profile, which allows for precise measurement with minimal straight pipe run requirements. This makes the V-CON an ideal solution for installations with limited space. Built for durability and performance, it offers a wide turndown ratio, low permanent pressure loss, and excellent repeatability, ensuring an efficient and cost-effective flow measurement solution for even the most challenging process conditions.
Technical Specifications:
- Principle: Advanced Differential Pressure (V-Cone Type)
- Accuracy: Up to ±0.5% of rate
- Repeatability: ±0.1%
- Turndown Ratio: 10:1 or greater
- Applicable Fluids: Liquid, Gas, Steam
- Straight Pipe Requirement: Typically 0-3D upstream, 0-1D downstream
- Line Sizes: 0.5″ to 72″ (DN15 to DN1800)
Marsen V-CON
Discover the Marsen V-CON, a high-performance V-Cone flow meter offering superior accuracy and a wide turndown ratio for reliable liquid, gas, and steam flow measurement in demanding industrial environments.
