Product Description
Meiyo Electric PTR-1NT Resistance Bulb
The Meiyo Electric PTR-1NT is a high-quality industrial resistance temperature detector (RTD), also known as a resistance bulb, designed for precise and reliable temperature measurement. It utilizes a Platinum (Pt100) sensing element, which is renowned for its excellent stability and accuracy, providing a nominal resistance of 100Ω at 0°C. Encased in a durable SUS304 stainless steel protection tube, the PTR-1NT is built to withstand demanding industrial environments. This sensor is an ideal choice for process control, monitoring, and automation systems where accurate temperature data is critical for operational efficiency and safety.
Technical Specifications:
- Model: PTR-1NT
- Sensing Element: Platinum (Pt) 100 Ω at 0°C
- Maximum Operating Temperature: 200°C
- Accuracy: Class B
- Protection Tube Material: SUS304 Stainless Steel
- Rated Current: 2mA
Meiyo Electric PTR-1NT Resistance Bulb
Discover the Meiyo Electric PTR-1NT, a robust Pt100 RTD sensor for precise industrial temperature measurement up to 200°C. Features a durable SUS304 stainless steel tube and Class B accuracy for reliable process control.
