Product Description
Mitsubishi FR-E720-2.2K
The Mitsubishi FR-E720-2.2K is a compact and high-performance variable frequency drive (VFD) from the renowned E700 series. Designed for exceptional power and reliability, this inverter offers advanced magnetic flux vector control for precise motor speed regulation in a wide range of applications. Its user-friendly design includes a built-in USB port for easy commissioning and monitoring via a PC, and an integrated digital dial for quick parameter adjustments. With features like a built-in braking transistor and Safety Torque Off (STO) functionality, the FR-E720-2.2K provides a powerful, safe, and efficient solution for controlling 3-phase induction motors.
Technical Specifications:
- Model: FR-E720-2.2K
- Power Capacity: 2.2 kW (3 HP)
- Input Voltage: 3-Phase 200-240V AC, 50/60Hz
- Rated Output Current: 11 A
- Control Method: Advanced magnetic flux vector control, V/F control
- Key Features: Built-in braking transistor, USB port for programming, Safety Torque Off (STO) according to EN 61800-5-2
- Enclosure Rating: IP20
Mitsubishi FR-E720-2.2K
Discover the Mitsubishi FR-E720-2.2K, a compact 2.2kW, 3-phase 200V class variable frequency drive. This powerful inverter offers advanced motor control, built-in safety features, and easy setup for industrial applications.
