Product Description
Murr 56622 M12 Shielded Sensor/Actuator Cable
The Murr 56622 is a high-quality, pre-assembled M12 sensor/actuator cable designed for reliable performance in demanding industrial environments. It features a straight M12 male connector on one end and an angled M12 female connector on the other, both with 4-pole, A-coded configurations. The cable is fully shielded to protect against electromagnetic interference (EMI), ensuring stable signal transmission for sensors, actuators, and other automation components. Its robust PUR (polyurethane) jacket provides excellent resistance to oils, abrasions, and chemicals, making it suitable for applications in robotics, machine building, and factory automation. The secure M12 screw-locking mechanism and IP67 rating guarantee a dust-tight and water-resistant connection.
Technical Specifications:
- Connector Type A: M12 Male, Straight, 4-Pole, A-Coded
- Connector Type B: M12 Female, Angled (90°), 4-Pole, A-Coded
- Operating Voltage: max. 250 V AC/DC
- Operating Current per Contact: max. 4 A
- Jacket Material: PUR (Polyurethane), Halogen-free
- Shielding: Yes, shielded
- Protection Rating: IP65, IP66K, IP67 (when connected)
- Temperature Range (fixed): -40…+80 °C

Murr 56622
Murr 56622 is a robust, shielded M12 sensor/actuator cable featuring a 4-pin straight male to angled female connector configuration, ideal for industrial automation and control systems.
