Product Description
Omron E3JK-DS30M1 Photoelectric Sensor
The Omron E3JK-DS30M1 is a high-performance, diffuse-reflective photoelectric sensor designed for reliable object detection in a wide range of industrial applications. Housed in a durable plastic casing, this sensor is easy to install and features a versatile power supply range, accepting both AC and DC voltage. Its long sensing distance and high-power LED ensure stable detection even in challenging environments. The built-in amplifier and simple sensitivity adjustment make it a user-friendly solution for automation tasks in packaging, logistics, and material handling systems.
Technical Specifications:
- Sensing Method: Diffuse-reflective
- Sensing Distance: 300 mm (30 cm)
- Power Supply Voltage: 12 to 240 VDC ±10% / 24 to 240 VAC ±10%
- Output Configuration: NPN open collector
- Light Source: Infrared LED (860 nm)
- Connection Method: Pre-wired cable (2 m)
- IP Rating: IP64

Omron E3JK-DS30M1
Omron E3JK-DS30M1 diffuse-reflective photoelectric sensor with a 30cm sensing range and versatile AC/DC power supply. Ideal for reliable object detection in industrial automation.
