Product Description
Parker 201-FKHSVWAA
The Parker 201-FKHSVWAA is a high-performance, pilot-operated solenoid valve from the Skinner 201 series. This 2-way, normally closed valve is engineered for reliable control of air, water, and light oil in demanding industrial applications. It features a durable forged brass body and FKM seals for excellent chemical compatibility and a wide temperature range. The valve is equipped with a NEMA 4X, 7, and 9 rated explosion-proof and watertight coil, making it an ideal choice for use in hazardous locations or environments requiring superior protection against moisture and corrosion.
Technical Specifications:
- Valve Function: 2-Way Normally Closed
- Body Material: Forged Brass
- Seal Material: FKM (Fluorocarbon)
- Port Size: 1/2″ NPT
- Orifice Size: 1/2″
- Voltage: 120V/60Hz, 110V/50Hz
- Max Operating Pressure Differential (MOPD): 150 PSI (10.3 bar)
- Coil Enclosure: NEMA 4X, 7, 9 – Watertight & Explosion-proof
Parker 201-FKHSVWAA
Shop the Parker 201-FKHSVWAA, a 1/2″ NPT normally closed solenoid valve. Features a brass body, FKM seals, and a 120V explosion-proof coil for reliable industrial fluid control.
