Product Description
Parker N35047004
The Parker N35047004 is a genuine replacement solenoid coil designed for a wide range of Parker Lucifer solenoid valves. This robust coil operates at 220/230V AC (50/60Hz) with a power rating of 8W, ensuring reliable actuation of the valve. It features Class F insulation and is designed for continuous duty (100% ED). When used with a suitable connector compliant with DIN 43650 Form A, it can achieve an IP65 protection rating, making it suitable for various industrial environments. This coil is essential for controlling fluid or gas flow in systems utilizing compatible Parker solenoid valves.
Technical Specifications:
- Manufacturer: Parker
- Part Number: N35047004
- Product Type: Solenoid Valve Coil
- Voltage: 220/230V AC
- Frequency: 50/60 Hz
- Power Consumption: 8W
- Electrical Connection: Spade terminals (DIN 43650 Form A compatible)
- Insulation Class: Class F
- Duty Cycle: 100% Continuous Duty (ED)
- Protection Rating: IP65 (when correctly assembled with mating connector)
- Ambient Temperature Range: Typically -20°C to +50°C (may vary based on specific valve application)
- Compatible Valve Series (Examples): Parker Lucifer E131F, 321H, 322G, E321G
Parker N35047004
Type:Parker N35047004
