Product Description
PARKER TDA032EW09B2NXW21
The Parker TDA032EW09B2NXW21 is a high-performance pneumatic cylinder belonging to the TDA series, designed according to ISO 15552 and VDMA 24562 standards. This specific configuration features a 32mm bore size and incorporates adjustable pneumatic cushioning at both ends for smooth deceleration and reduced impact. It includes a magnetic piston, allowing for non-contact position sensing using external sensors. Built for reliability and durability, this cylinder is suitable for a wide range of industrial automation applications requiring precise linear motion and control.
Technical Specifications:
- Manufacturer: Parker Hannifin
- Series: TDA
- Type: Pneumatic Cylinder
- Standard Compliance: ISO 15552, VDMA 24562
- Bore Size: 32 mm
- Cushioning: (EW) Adjustable pneumatic cushioning at both ends
- Piston Rod: Single Rod
- Piston: (X) Magnetic Piston Fitted
- Seals: (N) NBR (Nitrile Rubber) – Standard Temperature
- Port Type: (2) G Thread (BSPP)
- Rod End Configuration: (B) Specific rod/thread configuration
- Temperature Range: (W) Standard Temperature (-20°C to +80°C typical for NBR seals)
- Modification Code: (21) Specific factory options/modifications
- Note: Stroke length is not explicitly defined by ’09’ in this standard part number segment; it’s typically specified elsewhere or as a longer number. This code represents a specific configuration within the series.
PARKER TDA032EW09B2NXW21
Model:PARKER TDA032EW09B2NXW21
| Brand | Parker |
|---|---|
| Model | TDA032EW09B2NXW21 |
| Part No. | PARKER TDA032EW09B2NXW21 |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/parker-tda032ew09b2nxw21 |
