Product Description
Phoenix TRIO-PS/1AC/24DC/5
The Phoenix Contact TRIO-PS/1AC/24DC/5 is a robust and reliable single-phase primary-switched power supply designed for DIN rail mounting. Part of the TRIO POWER family, this unit is engineered for the demanding requirements of industrial machine building and control cabinets. It provides a stable 24V DC output with a 5A current, ensuring consistent power for your critical components. Its compact design saves valuable space in the cabinet, while the wide input voltage range and extended operating temperature make it versatile for global applications. Key features include a dynamic power boost, which delivers up to 150% of the nominal current for five seconds, making it ideal for starting heavy loads. The tool-free push-in connection technology simplifies and speeds up installation, reducing setup time and ensuring a secure connection.
Technical Specifications:
- Input Voltage Range: 85 V AC … 264 V AC / 99 V DC … 275 V DC
- Output: 24 V DC / 5 A
- Efficiency: > 89 % (at 230 V AC and nominal values)
- Dimensions (W x H x D): 40 mm x 130 mm x 115 mm
Phoenix TRIO-PS/1AC/24DC/5
Discover the Phoenix Contact TRIO-PS/1AC/24DC/5, a compact and efficient 24V DC, 5A single-phase DIN rail power supply. Engineered for reliability in industrial machinery, it features a wide input range and dynamic power boost for demanding applications.
