Product Description
Pilz 312610
The Pilz 312610, also known as the PNOZ s11 C, is a high-performance safety relay from the PNOZsigma product family. It is engineered to monitor a variety of safety functions, including E-STOP pushbuttons, safety gates, and light barriers. Operating on a 24V DC supply, this unit provides eight normally open (N/O) safety contacts and one normally closed (N/C) auxiliary contact, offering extensive connectivity for complex safety circuits. The PNOZ s11 C is designed to meet the highest safety standards, achieving up to PL e in accordance with EN ISO 13849-1 and SIL CL 3 in accordance with IEC 62061. Its compact design and user-friendly screw terminals make it an ideal solution for space-conscious industrial applications requiring robust and reliable machine safety.
Technical Specifications:
- Model: PNOZ s11 C
- Order Number: 312610
- Supply Voltage: 24 V DC
- Safety Contacts: 8 N/O (Normally Open)
- Auxiliary Contacts: 1 N/C (Normally Closed)
- Terminal Type: Screw terminals
- Safety Level: PL e (EN ISO 13849-1), SIL CL 3 (IEC 62061)
Pilz 312610
Discover the Pilz 312610 (PNOZ s11 C), a reliable 24V DC safety relay designed for machine safety applications. This unit features 8 N/O safety contacts and 1 N/C auxiliary contact, meeting top safety standards like PL e and SIL CL 3. Ideal for E-STOP and safety gate monitoring.
