Product Description
PR electronics PR5115B
The PR electronics PR5115B is a high-performance, 2-wire programmable transmitter designed for converting a wide range of input signals into a standard 4…20 mA output with HART® 7 protocol. This versatile device accepts inputs from RTD, thermocouple (TC), Ohm, and mV sensors, making it suitable for diverse industrial process applications. It features exceptional accuracy, high galvanic isolation, and is SIL 2 / SIL 3 certified, ensuring reliable and safe operation in critical systems. Its robust design and wide operating temperature range make it ideal for use in demanding environments.
Technical Specifications:
- Input Signals: RTD (Pt10/100/200/500/1000, Ni100/120/1000, Cu10/20/50/100), Thermocouple (Types B, E, J, K, L, N, R, S, T, U, W3, W5), Linear Resistance (0…10000 Ω), and Voltage (-800…+800 mV)
- Output Signal: 4…20 mA (2-wire) with HART® 7 digital communication
- Supply Voltage: 8.0…35 VDC
- Galvanic Isolation: 1.5 kVAC (Input to output)
- Safety Integrity Level (SIL): SIL 2 / SIL 3 capable according to IEC 61508
- Operating Temperature: -40°C to +85°C
PR electronics PR5115B
The PR electronics 5115B is a high-accuracy, 2-wire programmable transmitter with HART® 7 protocol. It converts RTD, TC, Ohm, and mV inputs to a standard 4-20mA signal and is SIL 2/3 certified for safety-critical applications.
