Product Description
Rexroth DBW10BA-52/350X6EG24N9DL R901055209
The Rexroth DBW10BA-52/350X6EG24N9DL is a high-performance, pilot-operated pressure relief valve designed for reliable pressure limitation in hydraulic systems. This size 10 valve features a subplate mounting design according to ISO 6264 standards. It is equipped with a 24V DC switching solenoid that allows for unloading the pressure or switching to a different pressure level, enhancing system efficiency and safety. The valve is adjustable up to a maximum pressure of 350 bar and includes a concealed manual override for emergency operation and an electrical position switch for monitoring. Its robust construction ensures long service life and consistent performance in demanding industrial applications.
Technical Specifications:
- Valve Type: Pilot-operated pressure relief valve with switching solenoid
- Size: NG10 (Size 10)
- Maximum Pressure Setting: 350 bar
- Solenoid Voltage: 24V DC
- Mounting: Subplate mounting, porting pattern to ISO 6264-06-09
- Features: Concealed manual override (N9), electrical position switch (D), and mating connector (L)
Rexroth DBW10BA-52/350X6EG24N9DL R901055209
Order the Rexroth DBW10BA-52/350X6EG24N9DL pilot-operated pressure relief valve. Size 10, 350 bar max pressure, with a 24V DC solenoid for precise hydraulic system control.
