Product Description
Rexroth Z2FS10-5-35/V R900517812
The Bosch Rexroth Z2FS10-5-35/V (R900517812) is a high-performance double throttle/check valve designed for precise hydraulic flow control. This sandwich plate valve is engineered to limit the main or pilot flow of one or two actuator ports. It achieves this by providing adjustable, metered flow in one direction and allowing free flow in the opposite direction. The Z2FS10-5-35/V model is configured for meter-out control and features a user-friendly rotary knob with a scale for easy adjustment. Its robust construction and FKM seals ensure reliability and compatibility with various hydraulic fluids, making it ideal for a wide range of industrial applications requiring accurate speed control of hydraulic actuators.
Technical Specifications:
- Valve Type: Double throttle/check valve, sandwich plate design
- Size: NG10 (Nominal Size 10)
- Maximum Operating Pressure: 315 bar (4568 PSI)
- Maximum Flow: 160 L/min (42.3 GPM)
- Control Type: Meter-out control
- Adjustment Type: Rotary knob with scale
- Seals: FKM (Viton)
- Mounting Pattern: ISO 4401-05-04-0-05
Rexroth Z2FS10-5-35/V R900517812
Buy the Rexroth Z2FS10-5-35/V R900517812, a size 10 double throttle/check valve for reliable meter-out hydraulic flow control. Features FKM seals and rotary knob adjustment.
| Brand | Rexroth |
|---|---|
| Model | Z2FS10-5-35/V R900517812 |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/rexroth-z2fs10-5-35-v-r900517812 |
