Product Description
Schneider ATV12HU15M2
The Schneider Electric ATV12HU15M2 is a compact and reliable variable speed drive from the Altivar 12 series, designed for simple commercial equipment and small industrial machines. This drive is specifically engineered to control three-phase asynchronous motors with a power rating of up to 1.5 kW (2 hp). Its user-friendly “plug and play” design, combined with an integrated EMC filter and Modbus communication protocol, ensures quick commissioning and seamless integration into existing systems. The ATV12HU15M2 is an ideal solution for applications such as conveyors, pumps, fans, and access barriers, offering enhanced performance and energy efficiency in a small footprint.
Technical Specifications:
- Product Range: Altivar 12
- Motor Power: 1.5 kW / 2 hp
- Rated Supply Voltage: 200…240 V AC, single-phase
- Output Voltage: 200…240 V AC, three-phase
- Supply Frequency: 50/60 Hz
- Continuous Output Current: 7.5 A at 4 kHz
- EMC Filter: Integrated Class C1
- Communication Port Protocol: Modbus
- Degree of Protection: IP20
Schneider ATV12HU15M2
Buy the Schneider Electric ATV12HU15M2, a compact 1.5 kW (2 hp) Altivar 12 variable speed drive. This VFD converts single-phase 200-240V input to control three-phase motors, ideal for simple machine applications.
