Product Description
Schneider ATV310HU22N4A
The Schneider Electric ATV310HU22N4A is a robust and compact variable speed drive from the Altivar 310 series, designed for controlling three-phase asynchronous motors. Engineered for simplicity and reliability, this drive is perfectly suited for common industrial applications such as material handling, packaging machinery, pumps, and fans. It features a power rating of 2.2 kW (3 hp) and operates on a 380-460V three-phase supply. The ATV310HU22N4A is built to withstand harsh environments with coated cards and the ability to operate at temperatures up to 55°C without derating. With integrated Modbus communication and a user-friendly interface, it offers a “plug and play” solution for quick commissioning and efficient motor control.
Technical Specifications:
- Product Range: Altivar 310
- Motor Power: 2.2 kW / 3 hp
- Supply Voltage: 380…460 V – 3-phase
- Nominal Output Current: 5.5 A
- EMC Filter: Integrated Class C3 EMC filter
- Communication Protocol: Modbus serial link
- IP Rating: IP20
Schneider ATV310HU22N4A
Buy the Schneider ATV310HU22N4A, a reliable 2.2 kW (3 hp) Altivar 310 variable speed drive for 3-phase 400V motors. This compact VFD is ideal for simple industrial machines and includes an integrated Modbus communication port.
