Product Description
Schneider Electric LV426101 Circuit Breaker
The Schneider Electric LV426101 is a highly reliable molded case circuit breaker (MCCB) from the Compact NSXm range, engineered for superior electrical protection in low-voltage distribution networks. This 3-pole (3P3D) breaker is equipped with a TM25D thermal-magnetic trip unit rated at 25A and offers a breaking capacity of 16kA at 380/415 V AC. A standout feature is its patented EverLink creep-compensating terminal blocks, which guarantee a secure, long-lasting bare cable connection that resists loosening due to thermal cycling or vibration, ensuring maximum safety and operational efficiency.
Technical Specifications:
- Brand: Schneider Electric
- Model/Reference: LV426101
- Product Range: Compact NSXm 63 E
- Poles Description: 3P 3D (3 Poles, 3 Protected)
- Trip Unit: TM-D (Thermal-Magnetic)
- Rated Current (In): 25 A
- Breaking Capacity (Icu): 16 kA at 380/415 V AC
- Connection Type: EverLink terminal block
- Certifications: CE Marked
Schneider Electric LV426101 Circuit Breaker
Shop the Schneider Electric LV426101 Compact NSXm MCCB. This 3-pole circuit breaker features a 25A TM25D trip unit, 16kA breaking capacity (380/415V), and secure EverLink terminals for reliable, commercial-grade low-voltage electrical protection.
