Product Description
Schneider MA-0186-100
The Schneider MA-0186-100 is a robust and reliable non-spring return, direct-coupled actuator designed for precise control of dampers and valves in HVAC systems. Engineered for efficiency, this 24 VAC actuator provides 70 lb-in (8 N-m) of torque with a floating (3-wire) control signal. It features a 90-second run time for 90-degree rotation, ensuring responsive adjustments. The MA-0186-100 model comes equipped with two integrated SPDT auxiliary switches, offering enhanced functionality for signaling and interlocking with other equipment. Its direct-coupled design allows for quick and easy installation on a wide range of round or square shafts, making it a versatile choice for both new installations and retrofits.
Technical Specifications:
- Torque: 70 lb-in (8 N-m)
- Control Signal: Floating (3-wire)
- Supply Voltage: 24 VAC, 50/60 Hz
- Power Consumption: 4 VA
- Running Time: 90 seconds at 60 Hz
- Auxiliary Switches: 2 x SPDT
- Shaft Compatibility: 3/8 to 5/8 in. (10 to 16 mm) round or 1/4 to 1/2 in. (6 to 13 mm) square
Schneider MA-0186-100
Order the Schneider MA-0186-100, a 70 lb-in, 24 VAC non-spring return damper actuator with floating control and two auxiliary switches. Ideal for reliable HVAC control applications.
