Product Description
Siemens 6DR5020-0NG30-0AB0
The Siemens 6DR5020-0NG30-0AB0 is a high-performance SIPART PS2 series electropneumatic positioner designed for the precise control of single-acting pneumatic linear or part-turn actuators. Encased in a durable Makrolon enclosure, it offers exceptional reliability and a high degree of protection (IP66). This model operates with a 0/4 to 20 mA input signal and features integrated HART communication, allowing for advanced configuration, monitoring, and diagnostics from a central control system. The inclusion of an Analog Output Module (AOM) provides a 4 to 20 mA feedback signal for continuous position tracking. Its intelligent features, such as automatic commissioning and self-diagnostics, make it a versatile and user-friendly solution for a wide range of process control applications.
Technical Specifications:
- Product Series: SIPART PS2
- Actuator Type: For single-acting actuators
- Communication Protocol: HART
- Input Signal: 0/4 to 20 mA
- Enclosure Material: Makrolon (Polycarbonate)
- Explosion Protection: None (for non-hazardous areas)
- Pneumatic Connection: M20x1.5
- Included Options: Analog Output Module (AOM) 4…20 mA
- Degree of Protection: IP66 / NEMA 4x
Siemens 6DR5020-0NG30-0AB0
Siemens 6DR5020-0NG30-0AB0 SIPART PS2 electropneumatic positioner for single-acting actuators. Features 4-20mA input, HART communication, and a robust Makrolon enclosure.
