Product Description
Siemens 7ML51101GD074AF3
The Siemens 7ML51101GD074AF3 is a SITRANS Probe LU240 ultrasonic level transmitter, engineered for reliable and continuous level measurement in a variety of industrial applications. This non-contacting device is ideal for monitoring liquids and slurries in storage tanks and simple process vessels. It features advanced Process Intelligence signal processing for superior accuracy, even in challenging environments with temperature changes or chemical fumes. The robust ETFE transducer offers excellent chemical compatibility, while the IP68-rated PBT enclosure ensures durability and protection against harsh conditions. This specific model comes with a 12-meter measurement range, a 2″ NPT process connection, a 4-20 mA HART output for seamless system integration, and an integrated Local Display Interface (LDI) for easy on-site configuration and monitoring.
Technical Specifications:
- Model Series: SITRANS Probe LU240
- Measurement Range: 12 meters (40 ft)
- Process Connection: 2″ NPT [(Taper), ANSI/ASME B1.20.1]
- Output: 4 to 20 mA with HART communication
- Transducer Material: ETFE
- Enclosure: Plastic (PBT), IP68 rated, with 2 x M20 x 1.5 cable inlets
- Display: Includes Local Display Interface (LDI)
- Approvals: General Purpose, CE, RCM, KCC

Siemens 7ML51101GD074AF3
Buy the Siemens 7ML51101GD074AF3, a SITRANS Probe LU240 ultrasonic level transmitter. This model features a 12-meter range, 4-20mA HART output, ETFE transducer, and an integrated display for reliable non-contact level measurement of liquids and slurries.
