Product Description

SMC IS3000-02L5

The SMC IS3000-02L5 is a high-precision digital pressure switch designed for accurate monitoring and control in pneumatic systems. It features a large, easy-to-read 2-color digital display that provides clear visual feedback of the pressure status, changing color when the set point is reached. This compact and lightweight switch offers excellent repeatability and is simple to set up, making it an ideal solution for a wide range of industrial automation applications. The IS3000-02L5 model comes with an M8 connector for fast and reliable electrical connection, enhancing installation efficiency and system reliability.

Technical Specifications:

  • Rated Pressure Range: -0.1 to 1.0 MPa

  • Fluid: Air, Non-corrosive gas, Non-flammable gas

  • Port Size: R1/4 (with M5 female thread)

  • Electrical Connection: Lead wire with M8 connector

  • Output Specification: 2 NPN open collector outputs

  • Supply Voltage: 12 to 24 VDC ±10%

  • Protection: IP40

SMC IS3000-02L5 Description

SMC IS3000-02L5

Shop the SMC IS3000-02L5 digital pressure switch. Features a 2-color display, R1/4 port, and M8 connector for precise pneumatic pressure monitoring from -0.1 to 1.0 MPa.

BrandSMC
ModelIS3000-02L5
CategoryElectrical
Linkhttps://www.echuan-hydraulic.com/product/smc-is3000-02l5
