Product Description
Stein Sohn A067.5031-000-0100
The Stein Sohn A067.5031-000-0100 is a robust and reliable diaphragm pressure switch designed for monitoring and controlling pressure in a wide range of industrial applications. Housed in a durable, seawater-resistant die-cast aluminum case, this switch is built to withstand harsh environments. It features an adjustable setting range from 0.1 to 1 bar and utilizes a high-quality SPDT microswitch for precise and dependable switching. Its compact design and standard connections make it easy to integrate into new or existing pneumatic, hydraulic, and general industrial systems for tasks such as pump control, compressor monitoring, and safety circuit activation.
Technical Specifications:
- Model: A067.5031-000-0100
- Type: Diaphragm Pressure Switch
- Setting Range: 0.1 … 1 bar (Adjustable)
- Maximum Operating Pressure: 10 bar
- Process Connection: G 1/4″ female thread
- Electrical Connection: Plug connector DIN EN 175301-803 Form A
- Contact Type: SPDT (Single Pole Double Throw) Microswitch
- Housing Material: Seawater-resistant die-cast aluminum
- IP Protection Rating: IP65
Stein Sohn A067.5031-000-0100
Order the Stein Sohn A067.5031-000-0100 diaphragm pressure switch, featuring a 0.1-1 bar adjustable range, IP65-rated aluminum housing, and G 1/4″ connection. Ideal for reliable pressure control in industrial systems.
