Product Description
VICKERS DG4V-3-6BL-M-U-H7-69-EN124
The Vickers DG4V-3-6BL-M-U-H7-69-EN124 is a high-performance, single-solenoid, direct-operated directional control valve from Eaton. Designed for industrial hydraulic applications, this NG6 (D03) size valve provides reliable control over the start, stop, and direction of fluid flow. It features a robust construction for long service life and mounts on the standard ISO 4401-03 interface, ensuring interchangeability. The valve is equipped with a 120V AC coil, a manual override for emergency or setup operations, and a DIN 43650 connector for straightforward electrical installation.
Technical Specifications:
- Valve Type: Solenoid Operated Directional Control Valve
- Series: DG4V-3
- Mounting Interface: ISO 4401-03 / CETOP 3 / NFPA D03
- Spool Type: 6B – Tandem center, spring offset
- Actuation: Single Solenoid, Spring Offset
- Coil Voltage: 120V AC 60Hz / 110V AC 50Hz
- Electrical Connection: DIN 43650 (ISO 4400)
- Maximum Operating Pressure: 350 bar (5075 psi)
- Manual Override: Push-pin type (M)
VICKERS DG4V-3-6BL-M-U-H7-69-EN124
Buy the Vickers DG4V-3-6BL-M-U-H7-69-EN124, a reliable NG6/D03 single solenoid directional valve with a 120V AC coil and tandem center spool for precise hydraulic system control.
| Brand | VICKERS |
|---|---|
| Model | DG4V-3-6BL-M-U-H7-69-EN124 |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/vickers-dg4v-3-6bl-m-u-h7-69-en124 |
