Product Description
VICKERS DGMX2-5-PP-BW-S-30
The Vickers DGMX2-5-PP-BW-S-30 is a high-performance, pilot-operated pressure reducing valve from Eaton. It is designed to maintain a controlled, lower pressure in a specific part of a hydraulic circuit compared to the main system pressure. This modular, stackable valve conforms to the ISO 4401 size 05 mounting standard, allowing for easy integration into compact hydraulic systems. Its robust construction ensures reliable and precise pressure control for various industrial applications, providing both pressure reducing and relieving functions for the secondary circuit.
Technical Specifications:
- Model Code: DGMX2-5-PP-BW-S-30
- Valve Type: Pilot Operated Pressure Reducing/Relieving Valve
- Mounting Interface: ISO 4401, Size 05 (NG10 / D05)
- Function: P-Port Pressure Reducing
- Pilot Drain: External (Port B)
- Spool Position: Normally Open
- Maximum Operating Pressure: 315 bar (4500 psi)
- Maximum Flow Rate: 100 L/min (26.4 US gpm)
- Hydraulic Fluid Compatibility: Mineral oil and fire-resistant fluids (with appropriate seals)
- Design Number: 30
VICKERS DGMX2-5-PP-BW-S-30
Model：VICKERS DGMX2-5-PP-BW-S-30
| Brand | VICKERS |
|---|---|
| Model | DGMX2-5-PP-BW-S-30 |
| Part No. | VICKERS DGMX2-5-PP-BW-S-30 |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/vickers-dgmx2-5-pp-bw-s-30 |
